12V 100AH 150AH 200AH Deep Cycle Storage Lifepo4 Lithium Battery Pack

If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.

Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.

Model	LFP100-12	LFP200-12	LFP300-12
Nominal Voltage(V)	12.8	12.8	12.8
Nominal Capacity(Ah)	100	200	300
Usable Capacity(Wh)	1280	2560	3840
Dimension(mm)	330*175*215	485*175*240	520*268*220
Weight(Kg)	11	25	30
Cycle Life	≥4000 @ 25℃	≥4000 @ 25℃	≥4000 @ 25℃
Working Temperature ℃	-20~55	-20~55	-20~55
Discharge Voltage (V)	12.8	12.8	12.8
Charge Voltage(V)	13.5~14.6	13.5~14.6	13.5~14.6
Internal Impedance(mΩ)	≤20	≤10	≤10
Charge / Discharge Current (A)	charge:50	charge:40	charge:60
	discharge:50	discharge:40	discharge:60
Design Life(Years)	20	20	10

Feature:

• Higher Energy Density and Smaller Size: (1) The energy density of Dobelay's LiFePO4 battery upgrades by 62% and 40% smaller size than other ordinary 12v 100Ah batteries; (2) Our batteries are all in line with UL1642 standards, which guarantee the quality of the products to a certain extent.
• Metal Frame Fixed to Battery Cells: Metal Frame can be used for better protection of battery cells from shock and vibration while vehicles are on rough roads, especially suitable for such vehicles as RVs, Golf carts, and light trucks.
• The Terminal of Lithium Iron Phosphate Battery: High-quality Copper material is used in the battery M8 terminal, which can prevent rusting so as to use for a long time. In the meanwhile, Copper material has good electrical conductivity.
• LiFePO4 Technology: (1) The chemical composition of LiFePO4 battery is stable and is not easy to catch fire, (2) LiFePO4 is non-toxicity and environmentally friendly; (3) 100ah LiFePO4 can be used in such places as travel trailers, boats, car audio, fish finder, solar panels, solar power, home battery backup system, server rack, off-grid application.
• Smart Built-in BMS: (1) to protect battery cells from damage, the cut-off function prevents charging under 32℉/0℃; (2) Our built-in Battery Management System (BMS) protects it from short-circuit, over-discharge, overcharge, overloading and overheating; (3) BMS supports 4S4P, reaching up to 51.2V 400Ah.
• Warranty: (1) 5-year warranty is offered; (2) Completing delivery around 48 states of the US (Guam, Hawaii, and Alaska excluded) based on a warehouse site are very convenient through cooperating with international famous logistics providers.

Hunan Chalong Fly Technology Co., Ltd., established in 2000, a comprehensive enterprise dedicated to the research, development, production and wholesale of Lithium battery pack, solar energy storage products.

With a group of professional and technical personnel in Li-ion battery pack and solar power products, Chalong Fly has strong technical force, strong product development and production capacity.

With the leading level in the field of lithium battery PACK in China, Chalong Fly has obtained many invention and utility model patents, and has undertaken the R&D and production of special lithium-ion batteries and special-purpose backup power in some major national projects. We have provided a lot of personalized design and product manufacturing for many different customers at home and abroad.

All of our products have strict quality assurance and good after-sales service, which are highly reflected and evaluated by domestic and foreign users. Our products are suitable for industrial and commercial energy storage system, electric vehicles, machineries and equipments, logstic industry, boats and other industries.

With the concept of "hard work and people-oriented", Chalong Fly sincerely serves the electric power, communication, military and electric vehicle industries. We will continue to launch new products, improve product quality, and contribute to providing green energy and creating green life with the safest,most reliable and affordable high-performance products.
